WF7021B0622.080000
XTAL OSC XO 622.0800MHZ LVPECLManufacturer: Diodes Incorporated
Categories: Oscillators
Quality Control: Learn More
Diodes Incorporated SaRonix-eCera™ WF series crystal oscillator, part number WF7021B0622-080000. This 622.08 MHz XO offers LVPECL output with a ±5ppm frequency stability. It operates from a 3.3V supply and features an Enable/Disable function. The component is housed in a 6-SMD, No Lead package with dimensions of 0.295" L x 0.197" W (7.50mm x 5.00mm) and a maximum seated height of 0.098" (2.50mm). It is designed for surface mounting and has a maximum supply current of 80mA. The operating temperature range is -40°C to 85°C. This oscillator is commonly utilized in high-speed networking, telecommunications, and high-performance computing applications. Packaging is provided on Cut Tape (CT).
Additional Information
Series: SaRonix-eCera™ WFRoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Cut Tape (CT)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Cut Tape (CT) |
| Package / Case | 6-SMD, No Lead |
| Size / Dimension | 0.295"" L x 0.197"" W (7.50mm x 5.00mm) |
| Mounting Type | Surface Mount |
| Output | LVPECL |
| Function | Enable/Disable |
| Type | XO (Standard) |
| Operating Temperature | -40°C ~ 85°C |
| Frequency Stability | ±5ppm |
| Voltage - Supply | 3.3V |
| Ratings | - |
| Current - Supply (Max) | 80mA |
| Height - Seated (Max) | 0.098"" (2.50mm) |
| Absolute Pull Range (APR) | - |
| Frequency | 622.08 MHz |
| Base Resonator | Crystal |
