MN3330001
XTAL OSC XO 33.3330MHZ CMOSManufacturer: Diodes Incorporated
Categories: Oscillators
Quality Control: Learn More
Diodes Incorporated MN3330001 is a 33.333 MHz Crystal Oscillator (XO) from the MN Series. This component features a standard CMOS output and operates at a supply voltage of 3.3V. The device is packaged in a 7.00mm x 5.00mm surface-mount form factor, supplied on tape and reel. Designed for reliable clock generation, it finds application in various industrial and consumer electronics sectors, including telecommunications, computing, and automotive systems where precise timing is critical. The operating temperature range is from -20°C to 70°C.
Additional Information
Series: MNRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Size / Dimension | 0.276"" L x 0.197"" W (7.00mm x 5.00mm) |
| Output | CMOS |
| Type | XO (Standard) |
| Operating Temperature | -20°C ~ 70°C |
| Voltage - Supply | 3.3V |
| Absolute Pull Range (APR) | - |
| Frequency | 33.333 MHz |
| Base Resonator | Crystal |
