ZXBM5210-SP-13

IC MOTOR DRIVER 3V-18V 8SO

Manufacturer: Diodes Incorporated

Categories: Motor Drivers, Controllers

Quality Control: Learn More

The Diodes Incorporated ZXBM5210-SP-13 is a fully integrated motor driver IC featuring a Power MOSFET half-bridge output configuration. Designed for brushed DC motor control, this component operates from a 3V to 18V supply and load voltage range. The interface is PWM, enabling flexible speed control. Its 8-SO-EP (Exposed Pad) package, a surface mountable 8-SOIC, facilitates efficient thermal management. This device is suitable for general-purpose applications across various industries requiring precise motor control. The ZXBM5210-SP-13 is supplied on a tape and reel for automated assembly.

Additional Information

Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:
Technical Details:
PackagingTape & Reel (TR)
Package / Case8-SOIC (0.154"", 3.90mm Width) Exposed Pad
Mounting TypeSurface Mount
FunctionDriver - Fully Integrated, Control and Power Stage
Current - Output-
InterfacePWM
Operating Temperature-40°C ~ 125°C (TA)
Output ConfigurationHalf Bridge (2)
Voltage - Supply3V ~ 18V
ApplicationsGeneral Purpose
TechnologyPower MOSFET
Voltage - Load3V ~ 18V
Supplier Device Package8-SO-EP
Motor Type - Stepper-
Motor Type - AC, DCBrushed DC
Step Resolution-
