AZ78L05Z-E1
IC REG LINEAR 5V 100MA TO92Manufacturer: Diodes Incorporated
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
Diodes Incorporated AZ78L05Z-E1 is a positive fixed 5V linear voltage regulator IC. This component delivers a stable 100mA output current and features over-current and over-temperature protection. With a maximum input voltage of 15V and a typical dropout voltage of 1.6V at 40mA, it is suitable for applications requiring regulated power. The AZ78L05Z-E1 is housed in a TO-92 package (TO-226-3, TO-92-3) and operates across a temperature range of -40°C to 125°C. Its typical quiescent current is 5mA, and it exhibits a PSRR of 62dB at 120Hz. This regulator is commonly utilized in consumer electronics, industrial controls, and automotive systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) |
| Output Type | Fixed |
| Mounting Type | Through Hole |
| Current - Output | 100mA |
| Operating Temperature | -40°C ~ 125°C |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 5 mA |
| Voltage - Input (Max) | 15V |
| Number of Regulators | 1 |
| Supplier Device Package | TO-92 |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 5V |
| Control Features | - |
| PSRR | 62dB (120Hz) |
| Voltage Dropout (Max) | 1.6V @ 40mA (Typ) |
| Protection Features | Over Current, Over Temperature |
