AZ1117CR-ADJTRG1
IC REG LINEAR POS ADJ 1A SOT89-3Manufacturer: Diodes Incorporated
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
Linear Voltage Regulator IC Positive Adjustable 1 Output 1A SOT-89-3
Additional Information
Series: AZ1117CRoHS Status: ROHS3 CompliantManufacturer Lead Time: 8 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-243AA |
| Output Type | Adjustable |
| Mounting Type | Surface Mount |
| Current - Output | 1A |
| Operating Temperature | -20°C ~ 125°C (TJ) |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 5 mA |
| Voltage - Input (Max) | 15V |
| Number of Regulators | 1 |
| Supplier Device Package | SOT-89-3 |
| Voltage - Output (Max) | 15V |
| Voltage - Output (Min/Fixed) | 1.25V |
| Control Features | - |
| PSRR | 70dB (120Hz) |
| Voltage Dropout (Max) | - |
| Protection Features | Thermal Shutdown |
