AP2213D-3.0TRG1
IC REG LINEAR 3V 500MA TO252-2Manufacturer: Diodes Incorporated
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
Diodes Incorporated AP2213D-3-0TRG1 is a positive fixed output linear voltage regulator. This device provides a 3V output voltage and is capable of delivering up to 500mA of current. The AP2213D-3-0TRG1 features a low quiescent current of 180 µA and a maximum input voltage of 18V. Protection features include over current, over temperature, and reverse polarity. With a typical dropout voltage of 0.7V at 500mA, this component is suitable for applications requiring efficient power regulation. The TO-252-3 (DPAK) surface mount package and tape and reel packaging are standard for high-volume manufacturing. This regulator is commonly utilized in consumer electronics, industrial control systems, and automotive applications.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Current - Output | 500mA |
| Operating Temperature | -40°C ~ 125°C |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 180 µA |
| Voltage - Input (Max) | 18V |
| Number of Regulators | 1 |
| Supplier Device Package | TO-252-3 |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 3V |
| Control Features | - |
| PSRR | 75dB (100Hz) |
| Voltage Dropout (Max) | 0.7V @ 500mA |
| Protection Features | Over Current, Over Temperature, Reverse Polarity |
| Current - Supply (Max) | 28 mA |
