DMN5L06VK-7
MOSFET 2N-CH 50V 0.28A SOT563Manufacturer: Diodes Incorporated
Categories: FET, MOSFET Arrays
Quality Control: Learn More
Diodes Incorporated DMN5L06VK-7 is a dual N-channel MOSFET array configured for surface mounting in a SOT-563 package. This device offers a 50V drain-to-source voltage (Vdss) and a continuous drain current (Id) of 280mA at 25°C. Featuring a logic level gate, the DMN5L06VK-7 has a maximum on-resistance (Rds On) of 2 Ohms at 50mA and 5V gate-source voltage. Its power dissipation is rated at 250mW, with an operating temperature range of -55°C to 150°C. Typical applications for this component include power management and signal switching in portable electronics and consumer devices.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SOT-563, SOT-666 |
| Mounting Type | Surface Mount |
| Configuration | 2 N-Channel (Dual) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| Power - Max | 250mW |
| Drain to Source Voltage (Vdss) | 50V |
| Current - Continuous Drain (Id) @ 25°C | 280mA |
| Input Capacitance (Ciss) (Max) @ Vds | 50pF @ 25V |
| Rds On (Max) @ Id, Vgs | 2Ohm @ 50mA, 5V |
| Gate Charge (Qg) (Max) @ Vgs | - |
| FET Feature | Logic Level Gate |
| Vgs(th) (Max) @ Id | 1V @ 250µA |
| Supplier Device Package | SOT-563 |
