DMN5L06DWK-7
MOSFET 2N-CH 50V 0.305A SOT363Manufacturer: Diodes Incorporated
Categories: FET, MOSFET Arrays
Quality Control: Learn More
Diodes Incorporated DMN5L06DWK-7 is a dual N-channel MOSFET array designed for surface mount applications. This component offers a 50V drain-to-source voltage and a continuous drain current of 305mA at 25°C. Featuring a logic level gate, the device exhibits a maximum on-resistance of 2 Ohms at 50mA and 5V. The DMN5L06DWK-7 is housed in a compact SOT-363 (6-TSSOP, SC-88) package, operating within a temperature range of -65°C to 150°C. With a maximum power dissipation of 250mW, this MOSFET array is suitable for use in portable electronics and power management circuits. The component is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 6-TSSOP, SC-88, SOT-363 |
| Mounting Type | Surface Mount |
| Configuration | 2 N-Channel (Dual) |
| Operating Temperature | -65°C ~ 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| Power - Max | 250mW |
| Drain to Source Voltage (Vdss) | 50V |
| Current - Continuous Drain (Id) @ 25°C | 305mA |
| Input Capacitance (Ciss) (Max) @ Vds | 50pF @ 25V |
| Rds On (Max) @ Id, Vgs | 2Ohm @ 50mA, 5V |
| Gate Charge (Qg) (Max) @ Vgs | - |
| FET Feature | Logic Level Gate |
| Vgs(th) (Max) @ Id | 1V @ 250µA |
| Supplier Device Package | SOT-363 |
