BAT54A-7-F-2477
DIODE ARR SCHOT 30V 200MA SOT23Manufacturer: Diodes Incorporated
Categories: Diode Arrays
Quality Control: Learn More
Diodes Incorporated BAT54A-7-F-2477 is a Schottky diode array featuring a common anode configuration with two diodes. This component offers a maximum DC reverse voltage (Vr) of 30V and an average rectified current (Io) of 200mA per diode. The forward voltage drop (Vf) is a maximum of 800mV at 100mA, with a reverse leakage current of 2µA at 25V. It boasts a reverse recovery time (trr) of 5ns, classifying it as a small signal diode. The device is designed for surface mounting within the TO-236-3, SC-59, or SOT-23-3 package. Operating temperature ranges from -65°C to 150°C. This diode array finds application in power supplies, switching circuits, and signal clamping across various industrial and consumer electronics sectors.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Mounting Type | Surface Mount |
| Speed | Small Signal =< 200mA (Io), Any Speed |
| Reverse Recovery Time (trr) | 5 ns |
| Technology | Schottky |
| Diode Configuration | 1 Pair Common Anode |
| Current - Average Rectified (Io) (per Diode) | 200mA |
| Supplier Device Package | SOT-23-3 |
| Operating Temperature - Junction | -65°C ~ 150°C |
| Voltage - DC Reverse (Vr) (Max) | 30 V |
| Voltage - Forward (Vf) (Max) @ If | 800 mV @ 100 mA |
| Current - Reverse Leakage @ Vr | 2 µA @ 25 V |
