AP1506-33K5G-13
IC REG BUCK 3.3V 3A TO263-5Manufacturer: Diodes Incorporated
Categories: DC DC Switching Regulators
Quality Control: Learn More
Diodes Incorporated AP1506-33K5G-13 is a fixed 3.3V, 3A buck switching regulator. This device operates with a switching frequency of 150kHz and features a TO-263-5 package for surface mounting. Designed for step-down voltage conversion, the AP1506-33K5G-13 accepts input voltages from 4.5V to 22V and provides a single positive output. It is not a synchronous buck converter. This component is commonly utilized in power supply designs across various industrial applications, including consumer electronics, telecommunications, and industrial automation. The packaging is Tape & Reel (TR).
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-263-6, D2PAK (5 Leads + Tab), TO-263BA |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Function | Step-Down |
| Current - Output | 3A |
| Operating Temperature | -20°C ~ 85°C (TA) |
| Output Configuration | Positive |
| Frequency - Switching | 150kHz |
| Voltage - Input (Max) | 22V |
| Topology | Buck |
| Supplier Device Package | TO-263-5 |
| Synchronous Rectifier | No |
| Voltage - Output (Max) | - |
| Voltage - Input (Min) | 4.5V |
| Voltage - Output (Min/Fixed) | 3.3V |
