PI6C22409LE
IC ZERO DELAY CLK BUFF 16TSSOPManufacturer: Diodes Incorporated
Categories: Clock Generators, PLLs, Frequency Synthesizers
Quality Control: Learn More
Diodes Incorporated PI6C22409LE is a single-circuit, low-skew clock buffer designed for high-frequency signal distribution. This device operates with a maximum frequency of 220MHz and features a 1:9 input-to-output ratio, offering a zero-delay clock buffering solution. The PI6C22409LE accepts TTL input signals and provides TTL outputs, ensuring compatibility with standard logic levels. Its 16-TSSOP package, with a 0.173" (4.40mm) width, is suitable for surface-mount applications. The component supports a voltage supply range of 2.375V to 3.6V and operates within an ambient temperature range of 0°C to 70°C. It incorporates a Phase-Locked Loop (PLL) with a bypass function. This clock buffer is utilized in various applications including computing, networking, and telecommunications infrastructure.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 16-TSSOP (0.173"", 4.40mm Width) |
| Mounting Type | Surface Mount |
| Output | TTL |
| Frequency - Max | 220MHz |
| Input | TTL |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 2.375V ~ 3.6V |
| Ratio - Input:Output | 1:9 |
| Differential - Input:Output | No/No |
| Supplier Device Package | 16-TSSOP |
| PLL | Yes with Bypass |
| Divider/Multiplier | No/No |
| Number of Circuits | 1 |
| Programmable | Not Verified |
