PI6C48535-01BLIE

IC CLK BUFFER 2:4 500MHZ 20TSSOP

Manufacturer: Diodes Incorporated

Categories: Clock Buffers, Drivers

Quality Control: Learn More

Diodes Incorporated PI6C48535-01BLIE is a high-performance clock fanout buffer designed for demanding timing applications. This multiplexer IC offers a 2:4 input to output ratio with a maximum frequency of 500 MHz, supporting LVCMOS, LVPECL, and LVTTL input standards. The output stage is specifically designed for LVPECL signaling. The PI6C48535-01BLIE is housed in a 20-TSSOP package, measuring 0.173" (4.40mm) in width, making it suitable for compact surface mount designs. It operates across a voltage range of 3V to 3.6V and is specified for an operating temperature range of -40°C to 85°C. This component is instrumental in clock distribution networks across various industries, including telecommunications, computing, and industrial automation, where precise clock signal integrity is paramount. The PI6C48535-01BLIE is packaged in tubes.

Additional Information

Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tube
Technical Details:
PackagingTube
Package / Case20-TSSOP (0.173"", 4.40mm Width)
Number of Circuits1
Mounting TypeSurface Mount
OutputLVPECL
TypeFanout Buffer (Distribution), Multiplexer
InputLVCMOS, LVPECL, LVTTL
Operating Temperature-40°C ~ 85°C
Voltage - Supply3V ~ 3.6V
Ratio - Input:Output2:4
Differential - Input:OutputNo/Yes
Supplier Device Package20-TSSOP
Frequency - Max500 MHz
