PBPC805

BRIDGE RECT 1P 600V 6A PBPC-8

Manufacturer: Diodes Incorporated

Categories: Bridge Rectifiers

Quality Control: Learn More

Diodes Incorporated PBPC805 is a single-phase, standard bridge rectifier designed for robust power applications. This through-hole component offers a 6A average rectified output current (Io) and a high peak reverse voltage rating of 600V. Its forward voltage drop (Vf) is a maximum of 1.1V at 4A, with a low reverse leakage current of 10 µA at 600V. The PBPC-8 package provides efficient thermal dissipation, suitable for operating temperatures ranging from -65°C to 125°C (TJ). This device is commonly utilized in power supplies, industrial motor controls, and consumer electronics where reliable AC to DC conversion is critical.

Additional Information

Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BoxDatasheet:
Technical Details:
PackagingBox
Package / Case4-Square, PBPC-8
Mounting TypeThrough Hole
Diode TypeSingle Phase
Operating Temperature-65°C ~ 125°C (TJ)
TechnologyStandard
Supplier Device PackagePBPC-8
Voltage - Peak Reverse (Max)600 V
Current - Average Rectified (Io)6 A
Voltage - Forward (Vf) (Max) @ If1.1 V @ 4 A
Current - Reverse Leakage @ Vr10 µA @ 600 V
