ZDT617TA
TRANS 2NPN 15V 3A SM8Manufacturer: Diodes Incorporated
Categories: Bipolar Transistor Arrays
Quality Control: Learn More
Diodes Incorporated ZDT617TA is a bipolar transistor array featuring two NPN transistors in a single package. This device offers a Collector-Emitter Breakdown Voltage (Vce) of 15V and a maximum Collector Current (Ic) of 3A. The 2 NPN (Dual) configuration provides a transition frequency of 120MHz and a power dissipation of 2.5W. Key specifications include a minimum DC Current Gain (hFE) of 300 at 200mA and 2V, and a Vce Saturation of 200mV at 50mA and 3A. The device exhibits a maximum Collector Cutoff Current of 100nA. Designed for surface mounting, it is supplied in a SOT-223-8 (SM8) package, presented on tape and reel. This component is suitable for applications in consumer electronics and industrial control systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SOT-223-8 |
| Mounting Type | Surface Mount |
| Transistor Type | 2 NPN (Dual) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Power - Max | 2.5W |
| Current - Collector (Ic) (Max) | 3A |
| Voltage - Collector Emitter Breakdown (Max) | 15V |
| Vce Saturation (Max) @ Ib, Ic | 200mV @ 50mA, 3A |
| Current - Collector Cutoff (Max) | 100nA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 300 @ 200mA, 2V |
| Frequency - Transition | 120MHz |
| Supplier Device Package | SM8 |
