API9221FCG-13
IC BATT CHG LI-ION 12UDFNManufacturer: Diodes Incorporated
Categories: Battery Chargers
Quality Control: Learn More
Diodes Incorporated API9221FCG-13 is a compact, highly integrated lithium-ion/polymer battery charger IC. Designed for efficient power management, this component features a constant-current, constant-voltage (CC/CV) charging profile with a maximum charge current of 1.2A. The device supports USB interface and includes robust fault protection mechanisms such as over-temperature, over-voltage, and reverse current protection for enhanced system reliability. Its programmable current feature allows for flexible charging solutions. The API9221FCG-13 is housed in a 12-UFDFN exposed pad package (U-DFN4030-12) for surface mounting, making it suitable for space-constrained applications in consumer electronics and portable devices. Operating within a temperature range of -40°C to 85°C, it supports battery pack voltages up to 4.2V with a maximum supply voltage of 6.7V. This component is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 12-UFDFN Exposed Pad |
| Number of Cells | - |
| Mounting Type | Surface Mount |
| Interface | USB |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Battery Chemistry | Lithium Ion/Polymer |
| Supplier Device Package | U-DFN4030-12 |
| Charge Current - Max | 1.2A |
| Programmable Features | Current |
| Fault Protection | Over Temperature, Over Voltage, Reverse Current |
| Voltage - Supply (Max) | 6.7V |
| Battery Pack Voltage | 4.2V |
| Current - Charging | Constant - Programmable |
