PAM8603ANHR
IC AMP CLASS D STEREO 3W 24SSOPManufacturer: Diodes Incorporated
Categories: Audio Amplifiers
Quality Control: Learn More
Diodes Incorporated PAM8603ANHR is a 2-channel stereo Class D audio amplifier IC. This highly efficient amplifier delivers 3W per channel into a 4-ohm load, operating from a supply voltage range of 2.5V to 5.5V. The PAM8603ANHR is housed in a 24-SSOP package, facilitating surface-mount assembly. Key features include integrated depop circuitry and robust protection against short-circuits and thermal events, enhancing system reliability. Its compact design and performance characteristics make it suitable for various audio applications across consumer electronics and portable devices. The operating temperature range for the component is -20°C to 85°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Features | Depop, Short-Circuit and Thermal Protection |
| Packaging | Tape & Reel (TR) |
| Package / Case | 24-SSOP (0.154"", 3.90mm Width) |
| Output Type | 2-Channel (Stereo) |
| Mounting Type | Surface Mount |
| Type | Class D |
| Operating Temperature | -20°C ~ 85°C (TA) |
| Voltage - Supply | 2.5V ~ 5.5V |
| Max Output Power x Channels @ Load | 3W x 2 @ 4Ohm |
| Supplier Device Package | 24-SSOP |
