PI6C20400AHEX
IC CLOCK BUFFER 1:4 28SSOPManufacturer: Diodes Incorporated
Categories: Application Specific Clock/Timing
Quality Control: Learn More
The Diodes Incorporated PI6C20400AHEX is a PCIe clock buffer designed for high-performance computing and communication systems. This single-circuit device offers a 1:4 output ratio, distributing a 400MHz HCSL clock signal from an HCSL input. Featuring integrated PLL functionality, it ensures precise clock synchronization for demanding applications. Its 28-SSOP package facilitates surface mount assembly. The PI6C20400AHEX operates within a voltage range of 3.135V to 3.465V and an industrial temperature range of -40°C to 85°C. This component is commonly utilized in PCI Express infrastructure, networking equipment, and server applications where reliable clock distribution is critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 40 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 28-SSOP (0.209"", 5.30mm Width) |
| Mounting Type | Surface Mount |
| Output | HCSL |
| Frequency - Max | 400MHz |
| Input | HCSL |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 3.135V ~ 3.465V |
| Main Purpose | PCI Express (PCIe) |
| Ratio - Input:Output | 1:4 |
| Differential - Input:Output | Yes/Yes |
| Supplier Device Package | 28-SSOP |
| PLL | Yes |
| Number of Circuits | 1 |
| Programmable | Not Verified |
