6091322130
LED PNL MT 9MM 12V BLACK YELLOWManufacturer: Dialight
Categories: Panel Indicators, Pilot Lights
Quality Control: Learn More
Dialight 609 Series panel mount LED indicator, part number 6091322130, offers a 12VDC operation with a typical current draw of 15mA. This component features a bright yellow LED with a 90mcd millicandela rating, housed in a black panel mount body. The round, domed lens has a diameter of 6.10mm, designed for a 9.40mm (0.37 inch) round panel cutout. This robust indicator is suitable for demanding applications across industrial control, telecommunications, and medical equipment sectors.
Additional Information
Series: 609RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Current | 15mA |
| Voltage | 12V |
| Type | LED |
| Millicandela Rating | 90mcd |
| Termination Style | - |
| Lens Color | - |
| Viewing Angle | - |
| Ingress Protection | - |
| Ratings | DC |
| Panel Cutout Dimensions | 0.37"" (9.40mm) |
| Wavelength - Peak | - |
| Lens Transparency | - |
| Lamp Color | Yellow |
| Panel Cutout Shape | Round |
| Lens Style | Round with Domed Top |
| Lens Size | 6.10mm Dia |
