5571432203
LED PNL MT 11/16"" 5V WT YEL/GRNManufacturer: Dialight
Categories: Panel Indicators, Pilot Lights
Quality Control: Learn More
Dialight 557 Series LED Panel Indicator, part number 5571432203, provides dual-color illumination in green and yellow. This component is rated for 5V and operates at 16mA for both colors. It features wire leads with a 0.50" (12.70mm) termination length for secure connections. The panel mount design requires a 0.69" (17.53mm) round cutout. Designed for robust operation, this indicator is water-resistant. Its application spans industrial automation, control panels, and equipment status indication where reliable visual feedback is critical. The device is supplied in bulk packaging.
Additional Information
Series: 557RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Current | 16mA Green, 16mA Yellow |
| Voltage | 5V Green, 5V Yellow |
| Type | LED |
| Millicandela Rating | - |
| Termination Style | Wire Leads - 0.50"" (12.70mm) |
| Lens Color | - |
| Viewing Angle | - |
| Ingress Protection | Water Resistant |
| Ratings | DC |
| Panel Cutout Dimensions | 0.69"" (17.53mm) |
| Wavelength - Peak | - |
| Lens Transparency | - |
| Lamp Color | Green, Yellow |
| Panel Cutout Shape | Round |
| Lens Style | Round with Flat Top |
| Lens Size | 17.80mm Dia |
