5973029202F
LED RED 4PLCC SMDManufacturer: Dialight
Categories: LED Indication - Discrete
Quality Control: Learn More
The Dialight 597 series 5973029202F is a red 625nm LED designed for surface mount applications. This 4-PLCC packaged component features a typical forward voltage of 2.15V at a test current of 50mA, producing a luminous intensity of 1800mcd. The LED exhibits a broad viewing angle of 120 degrees and has a peak wavelength of 634nm. Its compact dimensions of 3.20mm L x 2.80mm W with a maximum height of 2.10mm make it suitable for space-constrained designs. This component is commonly utilized in industrial controls, consumer electronics, and medical equipment where reliable visual indication is critical. Supplied in bulk packaging.
Additional Information
Series: 597RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | 4-PLCC |
| Color | Red |
| Size / Dimension | 3.20mm L x 2.80mm W |
| Mounting Type | Surface Mount |
| Millicandela Rating | 1800mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 2.15V |
| Lens Color | - |
| Current - Test | 50mA |
| Viewing Angle | 120° |
| Height (Max) | 2.10mm |
| Wavelength - Peak | 634nm |
| Wavelength - Dominant | 625nm |
| Supplier Device Package | 4-PLCC |
| Lens Transparency | - |
| Lens Style | Round with Flat Top |
| Lens Size | - |
