5973027502F
LED RED CLEAR 0402 SMDManufacturer: Dialight
Categories: LED Indication - Discrete
Quality Control: Learn More
Dialight 5973027502F is a red, clear lens, 0402 (1006 Metric) surface mount LED. This discrete indicator component offers a dominant wavelength of 620nm with a typical forward voltage of 2V. The LED is rated for 20mA test current, producing 85 millicandela of luminous intensity. Its compact 1.00mm L x 0.60mm W dimensions and 0.25mm maximum height are suitable for space-constrained applications. The square, flat-top lens design provides a wide 135° viewing angle. This component is utilized in various industrial and consumer electronics applications requiring clear visual indication.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: StripDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Strip |
| Package / Case | 0402 (1006 Metric) |
| Color | Red |
| Size / Dimension | 1.00mm L x 0.60mm W |
| Mounting Type | Surface Mount |
| Millicandela Rating | 85mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 2V |
| Lens Color | Colorless |
| Current - Test | 20mA |
| Viewing Angle | 135° |
| Height (Max) | 0.25mm |
| Wavelength - Peak | - |
| Wavelength - Dominant | 620nm |
| Supplier Device Package | 0402 |
| Lens Transparency | Clear |
| Lens Style | Square with Flat Top |
| Lens Size | 0.60mm |
