5942501002F
LED CBI 1.6MM ORNG SMD RAManufacturer: Dialight
Categories: Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Quality Control: Learn More
Dialight 594 Series LED Circuit Board Indicator, part number 5942501002F, is a single orange SMD LED designed for right-angle mounting. This component features a 1.60mm diameter round, domed lens and operates at a typical forward voltage of 1.8V and a current rating of 20mA. The millicandela rating is 38mcd. The surface mount, right-angle configuration is ideal for compact board designs in industrial automation, medical devices, and consumer electronics where clear visual status indication is critical. Packaged in strips for efficient automated placement.
Additional Information
Series: 594RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: StripDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Strip |
| Current | 20mA |
| Color | Orange |
| Voltage Rating | 1.8V |
| Mounting Type | Surface Mount, Right Angle |
| Millicandela Rating | 38mcd |
| Configuration | Single |
| Viewing Angle | - |
| Lens Type | - |
| Wavelength - Peak | - |
| Lens Style | Round with Domed Top |
| Lens Size | 1.60mm Dia |
