8532-33L
FIXED IND 470UH 590MA 1.03OHM SMManufacturer: Delevan
Categories: Fixed Inductors
Quality Control: Learn More
470 µH Unshielded Inductor 590 mA 1.03Ohm Max Nonstandard
Additional Information
Series: 8532RoHS Status: RoHS non-compliantManufacturer Lead Time: 13 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Tolerance | ±15% |
| Packaging | Tape & Reel (TR) |
| Package / Case | Nonstandard |
| Size / Dimension | 0.860"" L x 0.320"" W (21.84mm x 8.12mm) |
| Mounting Type | Surface Mount |
| Shielding | Unshielded |
| Type | - |
| Operating Temperature | -55°C ~ 125°C |
| DC Resistance (DCR) | 1.03Ohm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Current - Saturation (Isat) | 290mA |
| Material - Core | Ferrite |
| Inductance Frequency - Test | 1 kHz |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.286"" (7.26mm) |
| Inductance | 470 µH |
| Current Rating (Amps) | 590 mA |
