CY25200-ZXC009B
CY25200 - Programmable Spread SpManufacturer: Cypress Semiconductor Corp
Categories: Clock Generators, PLLs, Frequency Synthesizers
Quality Control: Learn More
The Cypress Semiconductor Corp CY25200-ZXC009B is a programmable spread spectrum clock generator. This single-circuit device operates up to 200MHz and features a PLL with bypass functionality. It accepts clock or crystal inputs and provides clock outputs. The CY25200-ZXC009B supports a voltage range of 2.375V to 2.625V and 3.135V to 3.465V. Its 1:6 ratio capability and spread spectrum modulation are beneficial for reducing electromagnetic interference (EMI) in applications such as computing, consumer electronics, and telecommunications. The component is housed in a 16-TSSOP (0.173", 4.40mm Width) package suitable for surface mounting.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 16-TSSOP (0.173"", 4.40mm Width) |
| Mounting Type | Surface Mount |
| Output | Clock |
| Frequency - Max | 200MHz |
| Type | Spread Spectrum Clock Generator |
| Input | Clock, Crystal |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Voltage - Supply | 2.375V ~ 2.625V, 3.135V ~ 3.465V |
| Ratio - Input:Output | 1:6 |
| Differential - Input:Output | No/No |
| Supplier Device Package | 16-TSSOP |
| PLL | Yes with Bypass |
| Divider/Multiplier | Yes/No |
| Number of Circuits | 1 |
