XREWHT-L1-0000-00B01
LED XLAMP COOL WHITE 10000K SMDManufacturer: Cree LED
Categories: LED White Lighting
Quality Control: Learn More
LED Lighting XLamp® XR-E White, Cool 5000K ~ 10000K 3.3V 350mA 90° 3529 (9073 Metric)
Additional Information
Series: XLamp® XR-ERoHS Status: Request inventory verificationManufacturer Lead Time: 8 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 3529 (9073 Metric) |
| Color | White, Cool |
| Size / Dimension | 0.354"" L x 0.276"" W (9.00mm x 7.00mm) |
| Mounting Type | Surface Mount |
| Voltage - Forward (Vf) (Typ) | 3.3V |
| Current - Test | 350mA |
| Viewing Angle | 90° |
| Current - Max | 1A |
| Supplier Device Package | SMD |
| Lumens/Watt @ Current - Test | 84 lm/W |
| Height - Seated (Max) | 0.181"" (4.60mm) |
| CCT (K) | 5000K ~ 10000K |
| CRI (Color Rendering Index) | 75 (Typ) |
| Flux @ 25°C, Current - Test | 97lm (94lm ~ 100lm) |
| Flux @ 85°C, Current - Test | - |
