MKRBWT-00-0000-0N0HF427F
LED XLAMP WARM WHITE 2700K 2SMDManufacturer: Cree LED
Categories: LED White Lighting
Quality Control: Learn More
LED Lighting XLamp® MK-R2 White, Warm 2700K 4-Step MacAdam Ellipse 36V 233mA 120° 2828 (7070 Metric)
Additional Information
Series: XLamp® MK-R2RoHS Status: Request inventory verificationManufacturer Lead Time: 8 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 2828 (7070 Metric) |
| Color | White, Warm |
| Size / Dimension | 0.276"" L x 0.276"" W (7.00mm x 7.00mm) |
| Mounting Type | Surface Mount |
| Voltage - Forward (Vf) (Typ) | 36V |
| Current - Test | 233mA |
| Viewing Angle | 120° |
| Current - Max | 420mA |
| Supplier Device Package | - |
| Lumens/Watt @ Current - Test | 90 lm/W |
| Height - Seated (Max) | 0.166"" (4.21mm) |
| CCT (K) | 2700K 4-Step MacAdam Ellipse |
| CRI (Color Rendering Index) | 80 |
| Flux @ 25°C, Current - Test | - |
| Flux @ 85°C, Current - Test | 755lm (730lm ~ 780lm) |
