CP41B-GFS-CL0N0694
LED GREEN CLEAR P4 T/HManufacturer: Cree LED
Categories: LED Indication - Discrete
Quality Control: Learn More
Cree LED's CP41B-GFS-CL0N0694 is a through-hole mounted, green discrete LED. This component features a 527nm dominant wavelength and a peak wavelength not specified. The LED offers a forward voltage of 3.6V at a test current of 30mA, producing a luminous intensity of 6565mcd. Its clear, domed-top round lens has a diameter of 3.00mm, providing a 70° viewing angle. Packaged in a 4-DIP (0.200", 5.08mm) format, this component is suitable for indication applications across various industries. The device dimensions are 7.60mm L x 7.60mm W with a maximum height of 5.94mm.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tube |
| Package / Case | 4-DIP (0.200"", 5.08mm) |
| Color | Green |
| Size / Dimension | 7.60mm L x 7.60mm W |
| Mounting Type | Through Hole |
| Millicandela Rating | 6565mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 3.6V |
| Lens Color | - |
| Current - Test | 30mA |
| Viewing Angle | 70° |
| Height (Max) | 5.94mm |
| Wavelength - Peak | - |
| Wavelength - Dominant | 527nm |
| Supplier Device Package | P4 |
| Lens Transparency | Clear |
| Lens Style | Round with Domed Top |
| Lens Size | 3.00mm Dia |
