C503B-RBN-CW0X0AA1
LED RED CLEAR 5MM ROUND T/HManufacturer: Cree LED
Categories: LED Indication - Discrete
Quality Control: Learn More
Cree LED C503B-RBN-CW0X0AA1 is a red, clear lens, 5mm round through-hole LED. This discrete indication component operates with a typical forward voltage of 2.1V and a test current of 20mA, producing a luminous intensity of 4430mcd. The dominant wavelength is 624nm, and it features a 23° viewing angle. Designed for through-hole mounting in a radial package, this component is commonly utilized in industrial automation, consumer electronics, and lighting applications where reliable visual feedback is critical. The LED is supplied in bulk packaging.
Additional Information
Series: -RoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | Radial |
| Color | Red |
| Size / Dimension | - |
| Mounting Type | Through Hole |
| Millicandela Rating | 4430mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 2.1V |
| Lens Color | Colorless |
| Current - Test | 20mA |
| Viewing Angle | 23° |
| Height (Max) | 10.10mm |
| Wavelength - Peak | - |
| Wavelength - Dominant | 624nm |
| Supplier Device Package | 5mm Round |
| Lens Transparency | Clear |
| Lens Style | Round with Domed Top |
| Lens Size | 5.00mm Dia |
