XQAROY-00-0000-000000602
LED XLAMP XQA BLUE 455NM SMDManufacturer: Cree LED
Categories: LED Color Lighting
Quality Control: Learn More
Cree LED Xlamp® XQ-A series blue LED, part number XQAROY-00-0000-000000602. This 0606 (1616 Metric) SMD device emits light with a peak wavelength of 455nm, within the 450nm to 460nm range. Designed for surface mounting, it features a typical forward voltage of 3.25V and a maximum forward current of 250mA, with a test current of 175mA. At 25°C test temperature, the luminous flux is rated at 230mW (210mW to 250mW). The component has a viewing angle of 105° and dimensions of 0.063" L x 0.063" W (1.60mm x 1.60mm), with a seated height not exceeding 0.068" (1.73mm). Packaged in tape and reel (TR). This component is suitable for applications in general lighting and signage.
Additional Information
Series: Xlamp® XQ-ARoHS Status: RoHS CompliantManufacturer Lead Time: 12 week(s)Product Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 0606 (1616 Metric) |
| Color | Blue |
| Wavelength | 455nm (450nm ~ 460nm) |
| Size / Dimension | 0.063"" L x 0.063"" W (1.60mm x 1.60mm) |
| Mounting Type | Surface Mount |
| Voltage - Forward (Vf) (Typ) | 3.25V |
| Current - Test | 175mA |
| Viewing Angle | 105° |
| Current - Max | 250mA |
| Supplier Device Package | SMD |
| Lumens/Watt @ Current - Test | - |
| Height - Seated (Max) | 0.068"" (1.73mm) |
| Temperature - Test | 25°C |
| Luminous Flux @ Current/Temperature | 230mW (210mW ~ 250mW) |
