XMLCTW-A0-0000-00C2ABBB1
LED XLAMP XML RGBW SMDManufacturer: Cree LED
Categories: LED Color Lighting
Quality Control: Learn More
Cree LED XLamp® XM-L Series XMLCTW-A0-0000-00C2ABBB1 is a 4-in-1 RGBW LED designed for high-performance lighting applications. This surface-mount device features individual emitters for Red (625nm), Green (528nm), Blue (458nm), and Neutral White (4000K). It supports a maximum drive current of 1A per channel, with typical forward voltages of 2.25V (Red), 3.3V (Green), and 3.1V (Blue/White). At a test current of 350mA and 25°C, luminous flux is rated at 67lm (Red), 101lm (Green), 27lm (Blue), and 90lm (White), with corresponding efficacy figures of 85 lm/W (Red), 87 lm/W (Green), 25 lm/W (Blue), and 83 lm/W (White). The component is housed in a 5.00mm x 5.00mm footprint (2020 metric) with a maximum seated height of 3.15mm and a wide 130° viewing angle. It is supplied in Tape & Reel packaging. This component is utilized in architectural lighting, stage lighting, and general illumination systems.
Additional Information
Series: XLamp® XM-LRoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 2020 (5050 Metric) |
| Color | Red, Green, Blue, White - Neutral (RGBW) |
| Wavelength | 625nm Red, 528nm Green, 458nm Blue, 4000K White |
| Size / Dimension | 0.197"" L x 0.197"" W (5.00mm x 5.00mm) |
| Mounting Type | Surface Mount |
| Voltage - Forward (Vf) (Typ) | 2.25V Red, 3.3V Green, 3.1V Blue, 3.1V White |
| Current - Test | 350mA Red, 350mA Green, 350mA Blue, 350mA White |
| Viewing Angle | 130° |
| Current - Max | 1A Red, 1A Blue, 1A Green, 1A White |
| Supplier Device Package | SMD |
| Lumens/Watt @ Current - Test | 85 lm/W Red, 87 lm/W Green, 25 lm/W Blue, 83 lm/W White |
| Height - Seated (Max) | 0.124"" (3.15mm) |
| Temperature - Test | 25°C |
| Luminous Flux @ Current/Temperature | 67lm Red, 101lm Green, 27lm Blue, 90lm White |
