CXB1816-0000-00PN0U0A40G
LED COB XLAMP NEUT WHT SQU 4000KManufacturer: Cree LED
Categories: LED COBs, Engines, Modules, Strips
Quality Control: Learn More
The Cree LED XLamp® CXB1816 is a high-power Chip On Board (COB) LED designed for demanding lighting applications. This component delivers a neutral white light with a correlated color temperature (CCT) of 4000K, specified within a 3-step MacAdam ellipse for tight color consistency. Featuring a high Color Rendering Index (CRI) of 90, it accurately renders the true colors of illuminated objects. The CXB1816 has a square light emitting surface (LES) with a diameter of 12.00mm, contributing to its 115° viewing angle. Rated for a maximum continuous current of 900mA, it achieves a typical luminous flux of 2182 lumens at 450mA and 85°C, with an efficacy of 139 lumens per watt at the test current. The LED operates at a forward voltage of 35V (typical). Its compact dimensions of 17.85mm x 17.85mm and a low profile of 1.70mm make it suitable for various luminaire designs. This component is commonly utilized in architectural lighting, retail displays, and industrial lighting. The Cree LED XLamp® CXB1816 is supplied in trays.
Additional Information
Series: XLamp® CXB1816RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tray |
| Color | White, Neutral |
| Wavelength | - |
| Size / Dimension | 17.85mm L x 17.85mm W |
| Type | Chip On Board (COB) |
| Configuration | Square |
| Voltage - Forward (Vf) (Typ) | 35V |
| Height | 1.70mm |
| Current - Test | 450mA |
| Viewing Angle | 115° |
| Lens Type | Flat |
| Current - Max | 900mA |
| Lumens/Watt @ Current - Test | 139 lm/W |
| CCT (K) | 4000K 3-Step MacAdam Ellipse |
| CRI (Color Rendering Index) | 90 |
| Light Emitting Surface (LES) | 12.00mm Dia |
| Temperature - Test | 85°C |
| Luminous Flux @ Current/Temperature | 2182lm (Typ) |
