CXA2011-0000-000P00G00E7
LED COB XLAMP WARM WHT SQ 3000KManufacturer: Cree LED
Categories: LED COBs, Engines, Modules, Strips
Quality Control: Learn More
Cree LED XLamp® CXA2011 Series Chip On Board (COB) LED, part number CXA2011-0000-000P00G00E7. This warm white LED features a 3000K color temperature and a CRI of 80, providing consistent light quality. The square light-emitting surface measures 22.00mm x 22.00mm, with a height of 2.28mm. It operates with a typical forward voltage of 40V and a maximum current of 1A, tested at 270mA. At the test conditions of 85°C and 270mA, it delivers 840 lumens with a luminous efficacy of 78 lm/W. The viewing angle is 120° with a flat lens type. This component is commonly utilized in general lighting, architectural lighting, and industrial lighting applications. Packaged in tubes.
Additional Information
Series: XLamp® CXA2011RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tube |
| Color | White, Warm |
| Wavelength | - |
| Size / Dimension | 22.00mm L x 22.00mm W |
| Type | Chip On Board (COB) |
| Configuration | Square |
| Voltage - Forward (Vf) (Typ) | 40V |
| Height | 2.28mm |
| Current - Test | 270mA |
| Viewing Angle | 120° |
| Lens Type | Flat |
| Current - Max | 1A |
| Lumens/Watt @ Current - Test | 78 lm/W |
| CCT (K) | 3000K |
| CRI (Color Rendering Index) | 80 |
| Light Emitting Surface (LES) | - |
| Temperature - Test | 85°C |
| Luminous Flux @ Current/Temperature | 840lm (780lm ~ 900lm) |
