CZRER52C4V3
DIODE ZENER 4.3V 150MW 0503Manufacturer: Comchip Technology
Categories: Single Zener Diodes
Quality Control: Learn More
Comchip Technology CZRER52C4V3 is a Zener diode featuring a 4.3V nominal breakdown voltage with a tight ±5% tolerance. This component is rated for 150 mW maximum power dissipation and is housed in a compact 0503 (1308 Metric) surface-mount package. It exhibits a low reverse leakage current of 5 µA at 1V and a maximum dynamic impedance (Zzt) of 95 Ohms. The forward voltage (Vf) at 10 mA is a maximum of 900 mV. Operating across a wide temperature range of -55°C to 125°C, this diode is commonly utilized in power management circuits, voltage regulation, and signal clipping applications across various industries, including telecommunications, consumer electronics, and automotive systems. It is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 32 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±5% |
| Packaging | Tape & Reel (TR) |
| Package / Case | 0503 (1308 Metric) |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 125°C |
| Voltage - Zener (Nom) (Vz) | 4.3 V |
| Impedance (Max) (Zzt) | 95 Ohms |
| Supplier Device Package | 0503 (1308 Metric) |
| Power - Max | 150 mW |
| Voltage - Forward (Vf) (Max) @ If | 900 mV @ 10 mA |
| Current - Reverse Leakage @ Vr | 5 µA @ 1 V |
