MSS1048-332NLC
FIXED IND 3.3UH 7.22A 10MOHM SMManufacturer: Coilcraft
Categories: Fixed Inductors
Quality Control: Learn More
3.3 µH Shielded Drum Core Inductor 7.22 A 10mOhm Max Nonstandard
Additional Information
Series: MSS1048RoHS Status: ROHS3 CompliantManufacturer Lead Time: Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±30% |
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | Nonstandard |
| Size / Dimension | 0.402"" L x 0.394"" W (10.20mm x 10.00mm) |
| Mounting Type | Surface Mount |
| Shielding | Shielded |
| Type | Drum Core |
| Operating Temperature | -40°C ~ 85°C |
| DC Resistance (DCR) | 10mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | 50MHz |
| Ratings | AEC-Q200 |
| Current - Saturation (Isat) | 4.62A |
| Material - Core | Ferrite |
| Inductance Frequency - Test | 100 kHz |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.201"" (5.10mm) |
| Inductance | 3.3 µH |
| Current Rating (Amps) | 7.22 A |
