CLU03Q-1206E1-503L7X4
LED COB CLU03Q COOL WHT SQ 5000KManufacturer: Citizen
Categories: LED COBs, Engines, Modules, Strips
Quality Control: Learn More
LED Lighting COBs Engines Modules Chip On Board (COB) CLU03Q White, Cool Square
Additional Information
Series: CLU03QRoHS Status: ROHS3 CompliantManufacturer Lead Time: 10 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | With Connector |
| Packaging | Tray |
| Color | White, Cool |
| Wavelength | - |
| Size / Dimension | 19.00mm L x 19.00mm W |
| Type | Chip On Board (COB) |
| Configuration | Square |
| Voltage - Forward (Vf) (Typ) | 33.8V |
| Height | 1.40mm |
| Current - Test | 540mA |
| Viewing Angle | - |
| Lens Type | Flat |
| Current - Max | 1.38A |
| Lumens/Watt @ Current - Test | 176 lm/W |
| CCT (K) | 5000K 3-Step MacAdam Ellipse |
| CRI (Color Rendering Index) | 70 |
| Light Emitting Surface (LES) | 14.50mm Dia |
| Temperature - Test | 85°C |
| Luminous Flux @ Current/Temperature | 3459lm (Typ) |
Request a Quote
