CS5466-ISZ
IC ENERGY METERING 1PHASE 24SSOPManufacturer: Cirrus Logic Inc.
Categories: Energy Metering
Quality Control: Learn More
Cirrus Logic Inc. CS5466-ISZ is a highly accurate single-phase energy metering IC. This component features a low supply current of 2.9mA and operates within a voltage range of 4.75V to 5.25V. Designed for surface mount applications, it is supplied in a 24-SSOP package. The CS5466-ISZ offers a measurement error of just 0.1% and an input impedance of 30kOhm, making it suitable for precision energy monitoring. Its operating temperature range is -40°C to 85°C. This IC is commonly employed in smart metering, power monitoring, and industrial automation systems where accurate energy measurement is critical.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 24-SSOP (0.209"", 5.30mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C |
| Current - Supply | 2.9mA |
| Measurement Error | 0.1% |
| Input Impedance | 30kOhm |
| Voltage - I/O High | 0.8V |
| Voltage - I/O Low | 0.2V |
| Meter Type | Single Phase |
| Supplier Device Package | 24-SSOP |
| Voltage - Supply | 4.75 V ~ 5.25 V |
