CS42L51-DNZ
IC CODEC STEREO W/HDPN AMP 32QFNManufacturer: Cirrus Logic Inc.
Categories: CODECS
Quality Control: Learn More
The Cirrus Logic Inc. CS42L51-DNZ is a stereo audio codec featuring a 24-bit resolution for both ADCs and DACs, providing a typical dynamic range of 98 dB. This component includes a headphone amplifier, making it suitable for applications requiring audio output. The device supports a serial data interface and operates with analog and digital supply voltages of 1.8V and 2.5V. Its Sigma-Delta architecture ensures high-fidelity audio processing. The CS42L51-DNZ is housed in a 32-QFN (5x5) surface-mount package and is designed for operation across a temperature range of -40°C to 85°C. This component is commonly utilized in consumer electronics and mobile device designs.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 20 week(s)Product Status: Last Time BuyPackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 32-VFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Type | Stereo Audio |
| Data Interface | Serial |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Analog | 1.8V, 2.5V |
| Voltage - Supply, Digital | 1.8V, 2.5V |
| Resolution (Bits) | 24 b |
| Dynamic Range, ADCs / DACs (db) Typ | 98 / 98 |
| Number of ADCs / DACs | 2 / 2 |
| S/N Ratio, ADCs / DACs (db) Typ | - |
| Sigma Delta | Yes |
| Supplier Device Package | 32-QFN (5x5) |
