UF4002 TR
DIODE GEN PURP 100V 1A DO41Manufacturer: Central Semiconductor Corp
Categories: Single Diodes
Quality Control: Learn More
Central Semiconductor Corp UF4002-TR is a 1A, 100V general-purpose rectifier diode. This axial leaded component, housed in a DO-41 (DO-204AL) package, features a fast recovery time of 50 ns, classifying it under speed ratings of Fast Recovery =< 500ns, > 200mA (Io). The diode exhibits a maximum forward voltage (Vf) of 1V at 1A and a reverse leakage current of 10 µA at its maximum reverse voltage (Vr) of 100V. Its junction operating temperature range is from -65°C to 150°C. With a capacitance of 20pF @ 4V, 1MHz, this device is suitable for applications in power supplies and general rectification circuits. The UF4002-TR is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | DO-204AL, DO-41, Axial |
| Mounting Type | Through Hole |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 50 ns |
| Technology | Standard |
| Capacitance @ Vr, F | 20pF @ 4V, 1MHz |
| Current - Average Rectified (Io) | 1A |
| Supplier Device Package | DO-41 |
| Operating Temperature - Junction | -65°C ~ 150°C |
| Voltage - DC Reverse (Vr) (Max) | 100 V |
| Voltage - Forward (Vf) (Max) @ If | 1 V @ 1 A |
| Current - Reverse Leakage @ Vr | 10 µA @ 100 V |
