L407CDT
RF PIN DIODE 180V 1W AXIAL GLASSManufacturer: CEL
Categories: RF Diodes
Quality Control: Learn More
The CEL L407CDT is a single RF PIN diode designed for high-frequency switching applications. This component features a 180V peak reverse voltage rating and can handle up to 100 mA of forward current. With a maximum power dissipation of 1W and a low on-resistance of 800mOhm at 50mA and 470MHz, it is optimized for efficient operation. The diode exhibits a capacitance of 2pF at 0V and 100MHz. Supplied in a DO-204AL (DO-41) axial glass package, the L407CDT is suitable for demanding environments with an operating temperature range up to 175°C. This device finds utility in various RF communication systems, including satellite communications and radar systems. The L407CDT is provided in Tape & Reel (TR) packaging.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | DO-204AL, DO-41, Axial |
| Diode Type | PIN - Single |
| Operating Temperature | 175°C (TJ) |
| Capacitance @ Vr, F | 2pF @ 0V, 100MHz |
| Resistance @ If, F | 800mOhm @ 50mA, 470MHz |
| Voltage - Peak Reverse (Max) | 180V |
| Supplier Device Package | DO-41 |
| Current - Max | 100 mA |
| Power Dissipation (Max) | 1 W |
