ACMD-6225-TR1
DUPLEXER BAND 25 1.4X1.8MM SMDManufacturer: Broadcom Limited
Categories: RF Multiplexers
Quality Control: Learn More
Broadcom Limited's ACMD-6225-TR1 is a surface-mount RF duplexer designed for efficient signal separation in wireless communication systems. This component operates across two distinct frequency bands: 1.85GHz to 1.915GHz and 1.93GHz to 1.995GHz, facilitating simultaneous transmission and reception on adjacent frequency channels. Housed in a compact 9-SMD, No Lead package, it offers excellent space efficiency for high-density board designs. The ACMD-6225-TR1 is typically utilized in mobile infrastructure, cellular base stations, and other telecommunications applications requiring robust RF filtering and isolation. Its tape and reel packaging ensures suitability for automated assembly processes.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 9-SMD, No Lead |
| Mounting Type | Surface Mount |
| Type | Duplexer |
| Frequency Bands (Low / High) | 1.85GHz ~ 1.915GHz / 1.93GHz ~ 1.995GHz |
| Low Band Attenuation (min / max dB) | - |
| High Band Attenuation (min / max dB) | - |
| Return Loss (Low Band / High Band) | - |
