HSMS-285C-BLK
RF DIODE SCHOTTKY 2V SOT323Manufacturer: Broadcom Limited
Categories: RF Diodes
Quality Control: Learn More
Broadcom Limited HSMS-285C-BLK is a Schottky RF diode, a critical component for high-frequency applications. This device features a series connection of two Schottky diodes within a compact SOT-323 package, also known as SC-70. With a maximum reverse voltage of 2V and a typical capacitance of 0.3pF at 1V and 1MHz, the HSMS-285C-BLK is engineered for precise RF signal manipulation. Its operating temperature range extends to 150°C, ensuring reliability in demanding environments. This component finds application in various sectors including telecommunications, wireless infrastructure, and consumer electronics where efficient RF switching and detection are paramount. The bulk packaging facilitates efficient integration into high-volume manufacturing processes.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | SC-70, SOT-323 |
| Diode Type | Schottky - 1 Pair Series Connection |
| Operating Temperature | 150°C (TJ) |
| Capacitance @ Vr, F | 0.3pF @ 1V, 1MHz |
| Resistance @ If, F | - |
| Voltage - Peak Reverse (Max) | 2V |
| Supplier Device Package | SOT-323 |
