HPND-4038
IC RF PIN DIODE BEAM LEAD SWManufacturer: Broadcom Limited
Categories: RF Diodes
Quality Control: Learn More
Broadcom Limited HPND-4038, a single PIN RF diode, offers robust performance for demanding RF switching applications. This component features a maximum reverse voltage of 60V and a maximum power dissipation of 250 mW. Its low capacitance of 0.045pF at 30V and 1MHz, coupled with a low resistance of 1 Ohm at 50mA and 100MHz, ensures efficient signal handling. Operating across a wide temperature range of -65°C to 150°C, the HPND-4038 is packaged in a 2-SMD, Flat Leads configuration, supplied in Bulk. This device is suitable for applications in aerospace, defense, and telecommunications where high-frequency switching and reliability are paramount.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 2-SMD, Flat Leads |
| Diode Type | PIN - Single |
| Operating Temperature | -65°C ~ 150°C |
| Capacitance @ Vr, F | 0.045pF @ 30V, 1MHz |
| Resistance @ If, F | 1Ohm @ 50mA, 100MHz |
| Voltage - Peak Reverse (Max) | 60V |
| Supplier Device Package | 83 |
| Power Dissipation (Max) | 250 mW |
