WS2512-BLK
IC AMP W-CDMA 1.92-1.98GHZ 10SMDManufacturer: Broadcom Limited
Categories: RF Amplifiers
Quality Control: Learn More
Broadcom Limited WS2512-BLK is a W-CDMA and HSPDA RF amplifier IC operating within the 1.92GHz to 1.98GHz frequency range. This surface-mount component offers a typical gain of 23.5dB to 26.5dB, with a supply current draw between 465mA and 510mA from a 3.2V to 4.2V supply. The WS2512-BLK is housed in a 10-SMD (4x4) package, specifically a 10-LDFN exposed pad, and is supplied on tape and reel. Its robust performance characteristics make it suitable for applications in mobile communications infrastructure and personal communication devices.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 10-LDFN Exposed Pad |
| Mounting Type | Surface Mount |
| Frequency | 1.92GHz ~ 1.98GHz |
| RF Type | W-CDMA, HSPDA |
| Voltage - Supply | 3.2V ~ 4.2V |
| Gain | 23.5dB ~ 26.5dB |
| Current - Supply | 465mA ~ 510mA |
| Noise Figure | - |
| P1dB | - |
| Test Frequency | - |
| Supplier Device Package | 10-SMD (4x4) |
