ALM-1812-BLKG
IC RF AMP GPS 12MCOBManufacturer: Broadcom Limited
Categories: RF Amplifiers
Quality Control: Learn More
Broadcom Limited ALM-1812-BLKG is a high-performance RF amplifier IC specifically designed for GPS applications. This component, utilizing a 12-MCOB (3.3x2.1) package, offers a typical gain of 19.1dB at a test frequency of 1.575GHz, ensuring robust signal reception. Its low noise figure of 1.66dB minimizes signal degradation, crucial for accurate positioning. Operating from a 3.6V supply with a current draw of 15mA, the ALM-1812-BLKG is suitable for power-sensitive designs. The surface mount package facilitates efficient assembly in high-density boards. This RF amplifier finds application in various sectors including automotive navigation, wearable technology, and advanced location-based services. The component is supplied in strip packaging.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: StripDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Strip |
| Package / Case | 12-SMD Module, No Lead |
| Mounting Type | Surface Mount |
| Frequency | - |
| RF Type | GPS |
| Voltage - Supply | 3.6V |
| Gain | 19.1dB |
| Current - Supply | 15mA |
| Noise Figure | 1.66dB |
| P1dB | -8dBm |
| Test Frequency | 1.575GHz |
| Supplier Device Package | 12-MCOB (3.3x2.1) |
