5962-9800104KFC
OPTOISO 1.5KV OPEN COLL 16FLATPKManufacturer: Broadcom Limited
Categories: Optocouplers, Optoisolators
Quality Control: Learn More
The Broadcom Limited 5962-9800104KFC is a logic output optoisolator featuring four channels with an open collector, Schottky clamped output. This component offers a data rate of 10MBd and a high common mode transient immunity (CMTI) of 1kV/µs, ensuring robust performance in noisy environments. With a minimum isolation voltage of 1500VDC, it is suitable for applications requiring significant electrical isolation. The device operates with a supply voltage range of 4.5V to 5.5V and supports a DC input type. Typical rise and fall times are 35ns, with maximum propagation delays of 100ns for both tpLH and tpHL. The 16-Flatpack package is designed for surface mounting. This optoisolator finds application in industrial automation, power systems, and telecommunications, where reliable signal isolation and data transfer are critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 99 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 16-Flatpack |
| Output Type | Open Collector, Schottky Clamped |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 125°C |
| Voltage - Supply | 4.5V ~ 5.5V |
| Voltage - Forward (Vf) (Typ) | 1.5V |
| Data Rate | 10MBd |
| Input Type | DC |
| Voltage - Isolation | 1500VDC |
| Current - DC Forward (If) (Max) | 20mA |
| Inputs - Side 1/Side 2 | 4/0 |
| Supplier Device Package | 16-Flatpack |
| Rise / Fall Time (Typ) | 35ns, 35ns |
| Common Mode Transient Immunity (Min) | 1kV/µs |
| Propagation Delay tpLH / tpHL (Max) | 100ns, 100ns |
| Number of Channels | 4 |
| Current - Output / Channel | 25 mA |
