ASMT-AW31-NVW01
LED ASMT-AX3X COOL WHT 7250K SMDManufacturer: Broadcom Limited
Categories: LED White Lighting
Quality Control: Learn More
Broadcom Limited ASMT-AW31-NVW01, an ASMT-Ax3x series LED, provides cool white illumination with a Correlated Color Temperature (CCT) of 7250K, ranging from 4500K to 10000K. This surface-mount component features a 2-SMD, Gull Wing package with dimensions of 7.40mm x 7.40mm and a seated height of 4.20mm. Optimized for demanding applications, it operates at a forward voltage of 3.2V and a test current of 350mA, delivering a typical luminous flux of 115 lumens and 103 lm/W. The maximum continuous forward current is rated at 700mA, with a wide viewing angle of 140°. This LED is suitable for general lighting, automotive, and display backlighting applications. Supplied on tape and reel.
Additional Information
Series: ASMT-Ax3xRoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 2-SMD, Gull Wing |
| Color | White, Cool |
| Size / Dimension | 0.291"" L x 0.291"" W (7.40mm x 7.40mm) |
| Mounting Type | Surface Mount |
| Voltage - Forward (Vf) (Typ) | 3.2V |
| Current - Test | 350mA |
| Viewing Angle | 140° |
| Current - Max | 700mA |
| Supplier Device Package | SMD |
| Lumens/Watt @ Current - Test | 103 lm/W |
| Height - Seated (Max) | 0.165"" (4.20mm) |
| CCT (K) | 7250K (4500K ~ 10000K) |
| CRI (Color Rendering Index) | - |
| Flux @ 25°C, Current - Test | 115lm (100lm ~ 130lm) |
| Flux @ 85°C, Current - Test | 98lm |
