HSMZ-A100-T30J1
LED RED CLEAR 2PLCC SMDManufacturer: Broadcom Limited
Categories: LED Indication - Discrete
Quality Control: Learn More
Broadcom Limited HSMZ-A100-T30J1 is a red, clear lens, 2-PLCC surface mount LED designed for indication applications. This discrete component operates with a typical forward voltage of 2.2V and a test current of 20mA. It emits light with a dominant wavelength of 630nm and a peak wavelength of 639nm, offering a wide 120° viewing angle. The LED features a colorless lens with a round, flat-top style, measuring 2.20mm in diameter. The component's dimensions are 3.20mm in length and 2.80mm in width, with a maximum height of 2.10mm. This device is supplied in a 2-PLCC package and is available on tape and reel for automated assembly. It finds application in consumer electronics, industrial control systems, and automotive lighting.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 2-PLCC |
| Color | Red |
| Size / Dimension | 3.20mm L x 2.80mm W |
| Mounting Type | Surface Mount |
| Millicandela Rating | - |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 2.2V |
| Lens Color | Colorless |
| Current - Test | 20mA |
| Viewing Angle | 120° |
| Height (Max) | 2.10mm |
| Wavelength - Peak | 639nm |
| Wavelength - Dominant | 630nm |
| Supplier Device Package | 2-PLCC |
| Lens Transparency | Clear |
| Lens Style | Round with Flat Top |
| Lens Size | 2.20mm Dia |
