HSMR-C320
LED BLUE 0603 SMDManufacturer: Broadcom Limited
Categories: LED Indication - Discrete
Quality Control: Learn More
Blue 473nm LED Indication - Discrete 3V 0603 (1608 Metric)
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 21 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 0603 (1608 Metric) |
| Color | Blue |
| Size / Dimension | 1.60mm L x 0.80mm W |
| Mounting Type | Surface Mount |
| Millicandela Rating | 653mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 3V |
| Lens Color | - |
| Current - Test | 20mA |
| Viewing Angle | 50° |
| Height (Max) | 1.08mm |
| Wavelength - Peak | 469nm |
| Wavelength - Dominant | 473nm |
| Supplier Device Package | 0603 |
| Lens Transparency | - |
| Lens Style | Round with Domed Top |
| Lens Size | 0.70mm Dia |
