HLMP-LM75-34NDD
LED GREEN DIFFUSED 4MM OVAL T/HManufacturer: Broadcom Limited
Categories: LED Indication - Discrete
Quality Control: Learn More
Broadcom Limited HLMP-LM75-34NDD is a green diffused 4mm oval through-hole LED. This discrete LED component operates with a typical forward voltage of 3.2V and a test current of 20mA, achieving a millicandela rating of 5130mcd. The dominant wavelength is 530nm, with a peak wavelength of 526nm. Its diffused lens style, with a domed top, provides a wide viewing angle of 40° by 100°. The component is supplied in Tape & Box packaging. This LED is commonly utilized in industrial and consumer electronics for status indication and general lighting applications.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Box (TB)Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Box (TB) |
| Package / Case | Radial |
| Color | Green |
| Size / Dimension | 3.80mm L x 3.00mm W |
| Mounting Type | Through Hole |
| Millicandela Rating | 5130mcd |
| Configuration | - |
| Voltage - Forward (Vf) (Typ) | 3.2V |
| Lens Color | - |
| Current - Test | 20mA |
| Viewing Angle | 40° x 100° |
| Height (Max) | 10.50mm |
| Wavelength - Peak | 526nm |
| Wavelength - Dominant | 530nm |
| Supplier Device Package | 4mm Oval |
| Lens Transparency | Diffused |
| Lens Style | Oval with Domed Top |
| Lens Size | 3.80mm x 3.00mm |
