HLMP-CM1A-450DD
LED GREEN CLEAR T-1 3/4 T/HManufacturer: Broadcom Limited
Categories: LED Indication - Discrete
Quality Control: Learn More
Broadcom Limited HLMP-CM1A-450DD is a green, clear lens, T-1 3/4 through-hole LED. This discrete indicator component operates with a typical forward voltage of 3.2V and a test current of 20mA, achieving a luminous intensity of 47000mcd. The dominant wavelength is 525nm, with a peak wavelength of 516nm. Its 15° viewing angle and domed top, colorless lens provide focused illumination. Packaged in cut tape, this component is suitable for applications in automotive, industrial control, and consumer electronics requiring reliable visual feedback.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Cut Tape (CT)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Cut Tape (CT) |
| Package / Case | Radial |
| Color | Green |
| Size / Dimension | - |
| Mounting Type | Through Hole |
| Millicandela Rating | 47000mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 3.2V |
| Lens Color | Colorless |
| Current - Test | 20mA |
| Viewing Angle | 15° |
| Height (Max) | - |
| Wavelength - Peak | 516nm |
| Wavelength - Dominant | 525nm |
| Supplier Device Package | T-1 3/4 |
| Lens Transparency | Clear |
| Lens Style | Round with Domed Top |
| Lens Size | 5mm, T-1 3/4 |
